Convey Split Type Scorching Machine manufacturer from China Drafone Autoparts Co., Ltd.

Place of Origin:

Zhejiang, China (Mainland)

Product Detail

Convey Split Type Scorching Machine

Convey Split Type Scorching Machine
Equipment Name	Convey Split Type Scorching Machine
Equipment Type	9200Lx1300Wx2100H
Disc Pad Size	60mm x 140mm Max.
Capacity	1200 pcs/h
A	Scorching Area
■Heeting Plate Material:Casted 304 Stainless Steel, 5pcs (470x660x50)
■Heating Tube Material: 18mm Dia heat resistence stainless steel heating tube, L=670MM,220V
■Temperature Control Area: 5 area, 650 degrees max
■Heating Length: 2400mm
■Scorching Time: APProx3min
B	Scorching Area Conveyor
■Conveying Speed: 0 - 10 m/min.
■Driving Control Method: Sensor Motor + Invertor + Stepper
■Driving Motor: Turbine 80:1,750W,1400
■Conveyor: Conveyor roller chain
■Tensioner: Cylinder, automatic tensioning
■Feeding Device: 4pcs, intermittent placing pads
C	Cooling Area
■Drive Motor: 0.75kw,60:1
■Convey Material: Stainless steel nets belt chain
■Belt Width: 750mm
■Cooling Fan: 20X180w
■Cooling Time: 8min
